Victron Quattro-II 12V 3000VA 120A Inverter Charger 120/240V Split Phase Dual AC Input | QUA122305130

Victron Quattro-II 12V 3000VA 120A Inverter Charger 120/240V Split Phase Dual AC Input

The Victron Quattro-II 12/3000 120-50/50 2x120V is a premium inverter charger designed for North American 120/240V split-phase electrical systems. Combining a 3000VA pure sine wave inverter, an advanced 120A adaptive battery charger, and an automatic transfer switch into one rugged unit, the Quattro-II delivers dependable backup power for RVs, marine vessels, off-grid homes, cabins, emergency power systems, and commercial energy installations.

Featuring dual AC inputs, the Quattro-II automatically switches between two independent power sources such as shore power and a generator. Its intelligent PowerAssist and PowerControl technologies prevent generator or utility overloads while supplementing available AC power from the battery whenever additional capacity is needed.

Key Features

• 3000VA Pure Sine Wave Inverter delivers clean, stable AC power for sensitive electronics and appliances.
• Integrated 120A Adaptive Battery Charger provides fast, efficient charging for lead-acid and compatible lithium battery systems.
• 120/240V Split-Phase Operation designed specifically for North American electrical systems.
• Dual AC Inputs automatically switch between shore power, generators, or other AC sources.
• Automatic Transfer Switch provides seamless transition between AC input and inverter power.
• PowerAssist Technology supplements limited shore or generator power using battery energy during high-demand loads.
• PowerControl prevents overload by intelligently managing battery charging based on available input current.
• Dual AC Outputs
  • Main output with uninterrupted UPS functionality
  • Secondary output operates only when external AC power is available
• UPS Function transfers to battery power in less than 18 milliseconds on the primary output, keeping sensitive electronics operating without interruption.
• Parallel Operation supports up to six Quattro-II units for increased inverter capacity.
• Three-Phase Capability allows three identical units to be configured for three-phase systems.
• Remote Monitoring & Configuration using Cerbo GX, GX devices, VRM Portal, VEConfigure software, or the optional VE.Bus Smart Dongle.
• Programmable Relay supports alarms, generator auto-start, lithium battery BMS communication, and custom automation.

Ideal Applications

• Off-Grid Solar Systems
• Residential Backup Power
• Whole-Home Energy Storage
• Marine Electrical Systems
• RVs & Motorhomes
• Commercial Backup Power
• Generator Integration
• Cabins & Remote Installations

Technical Specifications

• DC Battery Voltage: 12V
• Continuous Inverter Power: 3000 VA
• Continuous Output Power: 2400W
• Peak Surge Power: 5500W
• Maximum Battery Charging Current: 120A
• Output Voltage: 120VAC Pure Sine Wave
• Split-Phase Input: 120/240VAC
• Transfer Switch Rating: 50A
• Maximum AC Input Current: 50A Per Leg
• Maximum Efficiency: 93%
• PowerAssist: Yes
• PowerControl: Yes
• Dual AC Inputs: Yes
• Dual AC Outputs: Yes
• Programmable Relay: Yes
• VE.Bus Communication: Yes
• General Purpose Communication Ports: 2
• Remote On/Off: Yes
• Operating Temperature: -40°C to +65°C
• Protection Rating: IP22
• Dimensions: 579 × 319 × 168 mm (23 × 13 × 7 in.)
• Weight: 32.8 kg (72.3 lbs.)

Protection Features

• Output Short Circuit Protection
• Overload Protection
• High Battery Voltage Protection
• Low Battery Voltage Protection
• Over Temperature Protection
• Input Voltage Ripple Protection
• 120VAC Output Protection

Package Includes

• Victron Quattro-II 12/3000 120-50/50 2x120V Inverter Charger
• Installation Documentation

Manufacturer Information

• Brand: Victron Energy
• Manufacturer Part Number: QUA122305130
• UPC: 8719076057369

The Victron Quattro-II 12V 3000VA Inverter Charger delivers intelligent power management, seamless backup power, dual AC input flexibility, and advanced battery charging for demanding off-grid, marine, RV, and energy storage applications.
