Victron Energy Skylla TG 24V 100A Battery Charger 230V AC With Temperature Sensor

Victron Energy Skylla TG 24/100 Battery Charger 24V 100A 230V AC With Temperature Compensation

The Victron Energy Skylla TG 24/100 Charger is a professional-grade 24V 100A battery charger designed for marine, industrial, commercial, and large battery bank applications. Featuring precise voltage control, three-stage microprocessor-controlled charging, and automatic temperature compensation, the Skylla TG delivers reliable charging performance for a wide range of battery systems.

Designed for demanding installations, the Skylla TG provides one full-rated charging output plus a dedicated 4A auxiliary output for maintaining a second battery, such as a starter battery. The charger supports both sealed and unsealed battery systems and can be precisely adjusted to match specific battery charging requirements.

Advanced Three-Stage Intelligent Charging

Every Skylla TG charger uses a built-in microprocessor to accurately control the charging process through a multi-stage charging algorithm. This ensures batteries receive the correct charge profile while helping prevent overcharging, excessive gassing, and premature battery failure.

Automatic Temperature Compensation

The included battery temperature sensor automatically adjusts charging voltage based on battery temperature. This helps maintain optimal charging performance in changing environmental conditions and improves battery life.

Voltage Sense Technology

The Skylla TG includes battery voltage sensing to compensate for voltage loss caused by cable resistance. By measuring voltage directly at the battery terminals, the charger ensures the battery receives the correct charging voltage for improved efficiency and performance.

AC and DC Power Supply Capability

The Skylla TG can operate from both 230V AC and DC power sources, providing flexibility for marine, industrial, and backup power installations. Due to its highly stabilized output voltage, it can also be used as a reliable DC power supply when batteries or buffer capacitors are not connected.

Key Features:

• 24V 100A intelligent battery charger
• 230V AC input operation
• Additional 4A auxiliary charging output
• Three-stage microprocessor-controlled charging
• Compatible with sealed and unsealed battery systems
• Built-in battery temperature compensation
• Voltage sensing compensates for cable voltage loss
• Adjustable charging voltage for different battery types
• Can be used as a stabilized DC power supply
• Suitable for marine, industrial, and commercial applications

Technical Specifications:

• Manufacturer: Victron Energy
• Product: Skylla TG 24/100 Battery Charger
• Manufacturer Part Number: SDTG2401001
• UPC: 8719076025788
• Input Voltage: 230V AC
• AC Input Range: 185-264V AC
• DC Input Range: 180-400V DC
• Battery Voltage: 24V
• Main Charge Output: 100A
• Auxiliary Output: 4A
• Recommended Battery Capacity: 500-1000Ah
• Frequency: 45-65Hz
• Battery Connection: M8 studs
• AC Connection: Screw clamp (AWG 6)
• Dimensions: 14.4 x 9.9 x 10.1 inches
• Weight: 22 lbs (10 kg)

Applications:

• Marine battery charging systems
• Commercial vessels and yachts
• Industrial battery banks
• Large AGM and lead-acid battery systems
• Backup power installations
• DC power supply applications
• Professional energy storage systems

Package Includes:

• Victron Energy Skylla TG 24/100 Charger
• Mounting brackets
• Battery temperature sensor with 4.9 ft (1.5m) cable
• Instruction manual

The Victron Energy Skylla TG 24/100 Battery Charger provides dependable, precision-controlled charging for high-capacity 24V battery systems. With intelligent charging technology, temperature compensation, voltage sensing, and flexible AC/DC operation, it is an ideal choice for professional marine, industrial, and backup power applications.
