Victron Energy MultiPlus-II 24V 3000VA 2400W Inverter Charger 120V 70A Charger 50A Transfer Switch UL

Victron Energy MultiPlus-II 24V 3000VA 2400W Inverter Charger 120V 70A

The Victron Energy MultiPlus-II 24/3000 Inverter Charger is an advanced all-in-one power solution combining a powerful pure sine wave inverter, adaptive battery charger, automatic transfer switch, and intelligent energy management features in a single compact unit. Designed for off-grid solar systems, backup power, RV, marine, and Energy Storage System (ESS) applications, the MultiPlus-II delivers reliable 120V AC power while efficiently managing battery charging and AC power sources.

The MultiPlus-II combines the proven technology of the MultiPlus with advanced PowerControl and PowerAssist functionality. It automatically prevents overloads from limited AC sources such as generators or shore power connections by reducing charging demand or supplementing available AC power with energy from the battery bank.

With its built-in UPS functionality, the MultiPlus-II instantly switches to inverter operation during grid, shore power, or generator failure. Transfer time of less than 20 milliseconds keeps computers, electronics, and critical equipment operating without interruption.

When paired with a Victron GX device, the MultiPlus-II provides advanced remote monitoring and control through the Victron VRM platform, allowing users to view system performance, adjust settings, monitor battery status, and manage connected power equipment from virtually anywhere.

Key Features

• 24V Pure Sine Wave Inverter Charger combining inverter, charger, and transfer switch functionality
• 3000VA / 2400W Continuous AC Output for reliable household and mobile power applications
• 70A Battery Charger with adaptive charging technology for efficient battery management
• 50A Automatic Transfer Switch for seamless switching between AC sources and inverter power
• PowerAssist Technology boosts limited generator, shore, or grid power using battery energy
• PowerControl Technology prevents AC source overload by intelligently managing available power
• UPS Function provides uninterrupted power with transfer times under 20 milliseconds
• Energy Storage System (ESS) Compatible for solar and battery backup installations
• Compatible with Victron MPPT Solar Chargers and Grid-Tie PV Systems
• Remote Monitoring & Configuration through GX devices and Victron VRM
• Supports Parallel, Split Phase, and Three Phase Operation
• Programmable Relay for alarms, generator control, and system automation
• Remote On/Off Capability for advanced system integration

Ideal Applications

• Off-Grid Solar Power Systems
• Residential Backup Power
• RV Electrical Systems
• Marine Power Systems
• Cabins and Remote Properties
• Energy Storage Systems (ESS)
• Generator Backup Applications
• Commercial and Industrial Power Solutions

Technical Specifications

• Brand: Victron Energy
• Model: MultiPlus-II 24/3000
• Manufacturer Part Number: PMP242305102
• UPC: 8719076059202
• DC Input Voltage: 19-33V
• AC Output Voltage: 120VAC ±2%
• Output Frequency: 60Hz ±0.1%
• Continuous Output Power: 3000VA / 2400W
• Peak Power: 5500W
• Maximum Efficiency: 94%
• Battery Charger Output: 70A
• Transfer Switch Rating: 50A
• Maximum AC Input Current: 50A
• Auxiliary Output: 32A
• Communication: VE.Bus
• General Purpose Communication Ports: 2
• Battery Connection: M8 Bolts
• AC Connection: Screw Terminals 13mm² (6 AWG)
• Operating Temperature: -40°C to +65°C
• Humidity: Maximum 95% Non-Condensing
• Protection Rating: IP22
• Weight: 9 kg
• Dimensions: 536 x 277 x 147 mm

Package Includes

• Victron Energy MultiPlus-II 24/3000 Inverter Charger
• Installation Documentation

Product Overview

The Victron Energy MultiPlus-II 24/3000 120V Inverter Charger is engineered for customers who need dependable backup power, solar energy storage integration, and intelligent AC power management. With advanced inverter technology, powerful battery charging, UPS functionality, and remote monitoring capabilities, it provides a complete solution for modern off-grid and backup energy systems.
